Model
|
Measurement
|
Nominal value
|
Accuracy
|
Supply voltage
|
Second. Nominal Signal
|
|
CD100-S/SP18
CD series
|
Current
|
200 A
|
17 %
|
External DC Unipolar 48 to 48 V
|
Switch
Other Solid State
|
|
HLSR120-P/SP591
HLSR series
|
Current
|
120 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LZSR250-P/SP4
LZSR-P series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
IN500-S
IN500/1000/1200 series
|
Current
|
500 A
|
0.0018 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 666.6667 mA
|
|
HOF150-P/SP1
HOF-P series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSNDR700-S05
HSNDR series
|
Current
|
700 A
|
3.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
LAC300-S/SP7
LAC series
|
Current
|
400 A
|
1.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT300-T/SP13
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Unipolar 24 to 24 V
|
Instantaneous unidirectional
Current 100 mA
|
|
HAT163-T/SP17
HAT series
|
Current
|
163 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO120-NP/SP33-111D
HOxx-NP- series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
LF510-S/SPA5
LF510 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 125 mA
|
|
LTC600-T/SP12
LTC600-1000 series
|
Current
|
600 A
|
0.7 %
|
External DC Unipolar 24 to 24 V
|
Instantaneous unidirectional
Current 99.7 mA
|
|
HAS200-S/SP1
HAS series
|
Current
|
200 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.5 V
|
|
HO100-SW-0400
HOxx-SW- series
|
Current
|
100 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF150-PW
HOFxx-PW series
|
Current
|
150 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HSNBV100-R00
HSNBV series
|
Current
|
100 A, 100 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 V
|
|
LA306-S/SP4
LA306 series
|
Current
|
480 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 160 mA
|
|
LT300-S/SP9
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 150 mA
|
|
HAT163-S/SP6
HAT series
|
Current
|
163 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NP/SP33-111B
HOxx-NP- series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOF 300-P/SP1
HOF-P series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HTA 500-S/SP7
HTA series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 306-S/SP7
LF306 series
|
Current
|
300 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 150 mA
|
|
LT 505-S/SP22
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 100 mA
|
|
DK 300 B10
DK series
|
Current
|
150 A, 225 A, 300 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HAT 481-S/SP6
HAT series
|
Current
|
481 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 154-SW/SP4-0400
HOxx-SW- series
|
Current
|
154 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOYS 300-S/SP606-1106
HOYS series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HTC 90-S/SP2
HTC series
|
Current
|
90 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA4
LF310 series
|
Current
|
100 A
|
0.2 %
|
External DC Bipolar 15 to 20 V
|
Instantaneous
Current 100 mA
|
|
HTFS 400-P/SP5
HTFS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.25 V
|
|
LF 505-S/SP25
LF505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 100 mA
|
|
LTC 600-SF/SP20
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAH3DR 700-S0E
HAH3DR S0E series
|
Current
|
700 A
|
3.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
HC5FL 600-S/SP1
HC5FL series
|
Current
|
600 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
HO 250-S-010D
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 500-S/SP32-0100
HOYS series
|
Current
|
500 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.78125 V
|
|
LA 125-P/SP7
LA125 series
|
Current
|
125 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 100-S/SP37
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
LWSR 350-P/SP1
LWSR+ series
|
Current
|
350 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage Vref +/- 0.945 V
|
|
HAS 200-S/SP16
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 100-S/SP30-0100
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOF 150-P/SP1
HOF-P series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSNDR 700-S05
HSNDR series
|
Current
|
700 A
|
3.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
LAC 300-S/SP7
LAC series
|
Current
|
400 A
|
1.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT 300-T/SP13
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Unipolar 24 to 24 V
|
Instantaneous unidirectional
Current 100 mA
|
|
HAT 163-T/SP17
HAT series
|
Current
|
163 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NP/SP33-111D
HOxx-NP- series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOF 350-P/SP1
HOF-P series
|
Current
|
350 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HTB 100-TP/SP3
HTB series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 15 to 15 V
|
Instantaneous
Voltage Vc/2 +/- 1.66 V
|
|
LF 310-S/SP11
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 505-S/SP24
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 143 mA
|
|
DK 300 B420
DK series
|
Current
|
150 A, 225 A, 300 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Current 4-20mA
|
|
HAT 481-T/SP17
HAT series
|
Current
|
481 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP30-0100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 400-SW/SPFA0
HOYS-SW series
|
Current
|
400 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HO 200-S/SP31-1100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.8 V
|
|
HOYS 400-S/SP30-0100
HOYS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTFS 400-P/SP6
HTFS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.25 V
|
|
LF 510-S/SP26
LF510 series
|
Current
|
622 A
|
0.6 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 156 mA
|
|
LTC 600-SF/SP6
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAL 100-S/SP10
HAL series
|
Current
|
150 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 8 V
|
|
HC5FL 700-S/SP1
HC5FL series
|
Current
|
700 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
HO 250-S/SP30-0100
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 500-S/SP33-111D
HOYS series
|
Current
|
500 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
LA 200-P/SP10
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 100-S/SP63
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
LWSR 350-P/SP2
LWSR+ series
|
Current
|
350 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage Vref +/- 0.7 V
|
|
HAS 200-S/SP31
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 100-S/SP32-0107
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOF 180-P/SP1
HOF-P series
|
Current
|
180 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSTDR 300-000
HSTDR series
|
Current
|
300 A
|
2.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
LAC 300-S/SP8
LAC series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 50 mA
|
|
LT 300-T/SP41
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAT 200-S/SP1
HAT series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 126-SW/SP4-0400
HOxx-SW- series
|
Current
|
126 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 400-PW
HOFxx-PW series
|
Current
|
400 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTB 100-TP/SP9
HTB series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 1 V
|
|
LF 310-S/SP14
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 18 V
|
Instantaneous
Current 125 mA
|
|
LT 505-S/SP34
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 100 mA
|
|
DK 400 B10
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HAT 500-S/SP1
HAT series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
DK 400 B420 B
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HAT 500-S/SP24
HAT series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP32-0107
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOYS 400-S/SP33-111C
HOYS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HTR 200-SB/SP1
HTR series
|
Current
|
200 A
|
2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 510-S/SP34
LF510 series
|
Current
|
650 A
|
0.6 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 186 mA
|
|
LTC 600-S/SP1
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAL 400-S/SP10
HAL series
|
Current
|
400 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HAS 150-S
HAS series
|
Current
|
150 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HC5FW 700-S/SP66
HC5FW series
|
Current
|
700 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HOB 100-P/SP4
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOYS 700-SW/SPFA0
HOYS-SW series
|
Current
|
700 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 200-SD/SP4
LA200-500SD series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 40 mA
|
|
LT 300-S/SP45
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 100 mA
|
|
HAS 500-S/SP59
HAS series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0800
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 270-PW
HOFxx-PW series
|
Current
|
270 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTA 100-S/SP5
HTA series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
HOF 120-P/SP1
HOF-P series
|
Current
|
120 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSNBV-D15
HSNBV series
|
Current
|
200 A, 600 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
LA 205-S/SP15
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 300-S/SP7
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAS 600-P
HAS series
|
Current
|
600 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0A00
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-PW
HOFxx-PW series
|
Current
|
300 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTA 500-S/SP2
HTA series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 306-S/SP1
LF306 series
|
Current
|
250 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
HTA 500-S/SP7
HTA series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HOF 250-PW
HOFxx-PW series
|
Current
|
250 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HSTDR 600/SP2-000
HSTDR series
|
Current
|
600 A
|
2.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
LF 1005-S/SP11
LF1005 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 111.1 mA
|
|
LT 300-T/SP7
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
CAB 500-C/SP5-002
CAB500 series
|
Current
|
500 A
|
0.5 %
|
External DC Unipolar 8 to 16 V
|
Instantaneous
Other CAN.c
|
|
HAT 320-S/SP6
HAT series
|
Current
|
320 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-SW-0400
HOxx-SW- series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 700-P/SP1
HOF-P series
|
Current
|
700 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HTC 300-S/SP2
HTC series
|
Current
|
300 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA0
LF310 series
|
Current
|
300 A
|
0.2 %
|
External DC Bipolar 18 to 18 V
|
Instantaneous
Current 150 mA
|
|
LA 205-S/SP15
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 300-S/SP7
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAS 600-P
HAS series
|
Current
|
600 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0A00
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-PW
HOFxx-PW series
|
Current
|
300 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTA 500-S/SP2
HTA series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 306-S/SP1
LF306 series
|
Current
|
250 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 505-S/SP10
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 12 to 24 V
|
Instantaneous
Current 100 mA
|
|
DK 100 B420 B
DK series
|
Current
|
50 A, 75 A, 100 A
|
1 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HAT 400-S/SP1
HAT series
|
Current
|
400 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-S/SP33-111D
HOxx-S- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOYL 660-S/SPH00-0100
HOYL series
|
Current
|
600 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.6918 V
|
|
HTC 500-S/SP4
HTC series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA2
LF310 series
|
Current
|
300 A
|
0.2 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
LTC 500-S/SP5
LTC350-500 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 125 mA
|
|
HAH3DR 700-S0A
HAH3DR S0A series
|
Current
|
700 A
|
2.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HC5FL 500-S/SP1
HC5FL series
|
Current
|
500 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
HO 250-P/SP606-1106
HOxx-P- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOYS 500-SW/SPFA0
HOYS-SW series
|
Current
|
500 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 125-P/SP16
LA125 series
|
Current
|
125 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 62.5 mA
|
|
LTC 600-TF/SP18
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAS 100-S/SP31
HAS series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HC5FW 600-S/SP66
HC5FW series
|
Current
|
600 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HO 250-S/SP606-1106
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOYS 560-S/SP33-110G
HOYS series
|
Current
|
560 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
LA 200-P/SP3
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT 200-S/SP3
LT200 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
LZSR 250-P/SP3
LZSR-P series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.675 V
|
|
HAS 500-S/SP57
HAS series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0100
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HO 200-S/SP30-0100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 400-SW/SPFA0
HOYS-SW series
|
Current
|
400 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTFS 400-P/SP5
HTFS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.25 V
|
|
LF 505-S/SP25
LF505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 100 mA
|
|
LTC 600-SF/SP20
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAH3DR 700-S0E
HAH3DR S0E series
|
Current
|
700 A
|
3.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
HC5FL 600-S/SP1
HC5FL series
|
Current
|
600 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
HO 250-S-010D
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 500-S/SP32-0100
HOYS series
|
Current
|
500 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.78125 V
|
|
LA 125-P/SP7
LA125 series
|
Current
|
125 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 100-S/SP37
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
LA 200-P/SP10
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 100-S/SP63
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
LWSR 350-P/SP2
LWSR+ series
|
Current
|
350 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage Vref +/- 0.7 V
|
|
HAS 200-S/SP31
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 100-S/SP32-0107
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOF 180-P/SP1
HOF-P series
|
Current
|
180 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSTDR 300-000
HSTDR series
|
Current
|
300 A
|
2.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
LAC 300-S/SP8
LAC series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 50 mA
|
|
LT 300-T/SP41
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAT 200-S/SP1
HAT series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 126-SW/SP4-0400
HOxx-SW- series
|
Current
|
126 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 400-PW
HOFxx-PW series
|
Current
|
400 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTB 100-TP/SP9
HTB series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 1 V
|
|
LF 310-S/SP14
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 18 V
|
Instantaneous
Current 125 mA
|
|
LT 505-S/SP34
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 100 mA
|
|
DK 400 B10
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HAT 500-S/SP1
HAT series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP31-1100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.8 V
|
|
HOYS 400-S/SP30-0100
HOYS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
CAB 500-C/SP77
CAB500 series
|
Current
|
500 A
|
0.5 %
|
External DC Unipolar 8 to 16 V
|
Instantaneous
Other CAN.c
|
|
HAT 320-T/SP17
HAT series
|
Current
|
320 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-S/SP30-0100
HOxx-S- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYL 605-S/SPH00-0100
HOYL series
|
Current
|
550 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.6919 V
|
|
HTC 300-S/SP4
HTC series
|
Current
|
300 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA1
LF310 series
|
Current
|
300 A
|
0.25 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
LTC 350-S/SP5
LTC350-500 series
|
Current
|
350 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
HAH3DR 300-S0E
HAH3DR S0E series
|
Current
|
300 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HAX 500-S/SP11B
HAX series
|
Current
|
650 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 236-SW/SP4-0400
HOxx-SW- series
|
Current
|
236 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOYS 450-SW/SPFA0
HOYS-SW series
|
Current
|
450 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 100-TP/SP10
LA100P series
|
Current
|
100 A
|
0.45 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LF 510-S/SPA4
LF510 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 100 mA
|
|
LTC 600-T/SP10
LTC600-1000 series
|
Current
|
700 A
|
0.6 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 150 mA
|
|
HAS 150-S/SP31
HAS series
|
Current
|
150 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HLSR 100-P/SP14
HLSR-FeSi series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0.46 V
|
|
HOF 120-P/SP1
HOF-P series
|
Current
|
120 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
HSNBV-D15
HSNBV series
|
Current
|
200 A, 600 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
LA 205-S/SP15
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 300-S/SP7
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAS 600-P
HAS series
|
Current
|
600 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0A00
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-PW
HOFxx-PW series
|
Current
|
300 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTA 500-S/SP2
HTA series
|
Current
|
500 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 306-S/SP1
LF306 series
|
Current
|
250 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 505-S/SP10
LT505 series
|
Current
|
500 A
|
0.6 %
|
External DC Bipolar 12 to 24 V
|
Instantaneous
Current 100 mA
|
|
DK 100 B420 B
DK series
|
Current
|
50 A, 75 A, 100 A
|
1 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HAT 400-S/SP1
HAT series
|
Current
|
400 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-S/SP33-111D
HOxx-S- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOYL 660-S/SPH00-0100
HOYL series
|
Current
|
600 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.6918 V
|
|
HO 200-S/SP31-1100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.8 V
|
|
HOYS 400-S/SP30-0100
HOYS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTFS 400-P/SP6
HTFS series
|
Current
|
400 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.25 V
|
|
LTS 350-PB
LTS HC series
|
Current
|
350 A
|
0.8 %
|
External DC Unipolar 12 to 12 V
|
Instantaneous Unipolar
Voltage 6 +/- 1.4 V
|
|
LTS 400-PB
LTS HC series
|
Current
|
400 A
|
0.8 %
|
External DC Unipolar 12 to 12 V
|
Instantaneous Unipolar
Voltage 6 +/- 1.6 V
|
|
HLSR 120-P/SP59
HLSR series
|
Current
|
120 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LWSR 250-P
LWSR series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.781 V
|
|
AI-P1A
AI-P1A series
|
Current
|
100 A, 200 A, 300 A, 400 A, 500 A, 600 A, 800 A, 1000 A, 1500 A, 2000 A, 4000 A, 5000 A
|
0.5 %
|
External DC Unipolar 16.8 to 31.2 V
|
Instantaneous
Current 1000 mA
|
|
HOB 100-P
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
|
|
|
|
|
|
您的当前位置：
