Model
|
Measurement
|
Nominal value
|
Accuracy
|
Supply voltage
|
Second. Nominal Signal
|
|
CD100-S/SP18
CD series
|
Current
|
200 A
|
17 %
|
External DC Unipolar 48 to 48 V
|
Switch
Other Solid State
|
|
HLSR120-P/SP591
HLSR series
|
Current
|
120 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
CDT-SF0.3-S4/SP20
CDT-SF series
|
Current
|
48 A
|
15 %
|
External DC Unipolar 5 to 5 V
|
SPI Bipolar
Other SPI
|
|
GXM AFE150 50010A
GXM AFE series
|
Current
|
60 A
|
2 %
|
External DC Bipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 V
|
|
GXM AFE180 50010Q
GXM AFE series
|
Current
|
72 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage Vref +/- 2.5 V
|
|
LZSR250-P/SP4
LZSR-P series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HAT233-S/SP6
HAT series
|
Current
|
233 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO200-S/SP32-0107
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HSNBV100-R00
HSNBV series
|
Current
|
100 A, 100 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 V
|
|
LAH100-P/SP10
LAH series
|
Current
|
100 A
|
0.25 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LF310-S/SPA4
LF310 series
|
Current
|
100 A
|
0.2 %
|
External DC Bipolar 15 to 20 V
|
Instantaneous
Current 100 mA
|
|
HAS150-S
HAS series
|
Current
|
150 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NP/SP33-111B
HOxx-NP- series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOF 200-PW
HOFxx-PW series
|
Current
|
200 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 200-P/SP12
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT 300-S/SP45
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 100 mA
|
|
HAT 163-S/SP6
HAT series
|
Current
|
163 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 154-SW/SP4-0400
HOxx-SW- series
|
Current
|
154 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOYS 100-S/SP125-0100
HOYS series
|
Current
|
64 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LA 55-P/SP26
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LT 200-S/SP3
LT200 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
HAS 75-S/SP16
HAS series
|
Current
|
75 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-S/SP33-111D
HOxx-S- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOF 65-P/SP1
HOF-P series
|
Current
|
65 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
LA 55-P/SP21
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LT 300-T/SP7
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
LA 55-P/SP26
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LTC 200-SF/SP2
LTC200-400 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 200 mA
|
|
HLSR 50-P/SP3
HLSR series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HO 250-P/SP606-1106
HOxx-P- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
LF 306-S/SP7
LF306 series
|
Current
|
300 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 150 mA
|
|
DK 400 B10
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HO 100-SW-0400
HOxx-SW- series
|
Current
|
100 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HO 80-NPW-0100
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTC 90-S/SP2
HTC series
|
Current
|
90 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA4
LF310 series
|
Current
|
100 A
|
0.2 %
|
External DC Bipolar 15 to 20 V
|
Instantaneous
Current 100 mA
|
|
HAS 150-S
HAS series
|
Current
|
150 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NP/SP33-111B
HOxx-NP- series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOF 200-PW
HOFxx-PW series
|
Current
|
200 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 200-P/SP12
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
HO 250-P/SP606-1106
HOxx-P- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HTB 50-TP/SP3
HTB series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 15 to 15 V
|
Instantaneous
Voltage Vc/2 +/- 1.66 V
|
|
LF 306-S/SP7
LF306 series
|
Current
|
300 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 150 mA
|
|
DK 400 B10
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HO 100-SW-0400
HOxx-SW- series
|
Current
|
100 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
DK 400 B420 B
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HO 100-S/SP30-0100
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HO 80-NPW-0A00
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTR 200-SB/SP1
HTR series
|
Current
|
200 A
|
2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LKSR 75-NP
LKSR series
|
Current
|
75 A
|
0.4 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.46875 V
|
|
LT 100-S/SP63
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
HAS 200-S/SP31
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-NPW-0A00
HOxx-NPW series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-PW
HOFxx-PW series
|
Current
|
300 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 205-S/SP15
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 300-T/SP41
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAT 233-T/SP17
HAT series
|
Current
|
233 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP33-111D
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HSTDR 300-000
HSTDR series
|
Current
|
300 A
|
2.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 V
|
|
LAH 100-P/SP3
LAH series
|
Current
|
100 A
|
0.25 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 66.6 mA
|
|
ATO-75-B1I-D10/SP1
ATO1B1I series
|
Current
|
75 A
|
1 %
|
Self Powered
|
Instantaneous
Current 75 mA
|
|
HLSR 50-P/SP8
HLSR series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HO 250-S-010D
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTB 75-P
HTB series
|
Current
|
75 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 310-S/SP11
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
DK 400 B420 U
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous unidirectional
Current 4-20mA
|
|
HO 100-S/SP32-0107
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOB 100-P/SP4
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LA 100-P/SP4
LA100P series
|
Current
|
100 A
|
0.9 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LPSR 50-NP/SP2
LPSR series
|
Current
|
50 A
|
0.45 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LF 310-S/SPA1
LF310 series
|
Current
|
300 A
|
0.25 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
HAS 100-S/SP16
HAS series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0800
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 150-P/SP1
HOF-P series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
LA 125-P/SP7
LA125 series
|
Current
|
125 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 125 mA
|
|
LT 200-S
LT200 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar -10 to 20 V
|
Instantaneous
Current 100 mA
|
|
HAS 50-S/SP16
HAS series
|
Current
|
50 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-S/SP30-0100
HOxx-S- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOF 350-P/SP1
HOF-P series
|
Current
|
350 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
LA 55-P/SP2
LA55 series
|
Current
|
50 A
|
0.9 %
|
External DC Bipolar 14 to 14 V
|
Instantaneous
Current 50 mA
|
|
LZSR 250-P/SP1
LZSR-P series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.675 V
|
|
DK 300 B10
DK series
|
Current
|
150 A, 225 A, 300 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-10V
|
|
HLSR 80-P/SP13
HLSR-FeSi series
|
Current
|
80 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 0.8 V
|
|
HO 50-S/SP30-0100
HOxx-S- series
|
Current
|
50 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTC 300-S/SP4
HTC series
|
Current
|
300 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SPA1
LF310 series
|
Current
|
300 A
|
0.25 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
HAS 100-S/SP31
HAS series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 120-NPW-0A00
HOxx-NPW series
|
Current
|
120 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 180-P/SP1
HOF-P series
|
Current
|
180 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
LA 200-P/SP10
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
HAT 233-S/SP6
HAT series
|
Current
|
233 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP32-0107
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HSNBV 100-R00
HSNBV series
|
Current
|
100 A, 100 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 V
|
|
LAH 100-P/SP10
LAH series
|
Current
|
100 A
|
0.25 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LWSR 350-P/SP1
LWSR+ series
|
Current
|
350 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage Vref +/- 0.945 V
|
|
CASR 50-NP/SP3
CASR-NP series
|
Current
|
50 A
|
0.8 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HLSR 62-P/SPH00
HLSR series
|
Current
|
48 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.6914 V
|
|
HO 250-S/SP33-1116
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HTC 250-S/SP2
HTC series
|
Current
|
250 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LF 310-S/SP15
LF310 series
|
Current
|
300 A
|
0.2 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
DK 400 B5
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HO 100-S/SP606-1106
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOB 50-P/SP34
HOB series
|
Current
|
50 A
|
1.45 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.92 V
|
|
LA 100-P/SP6
LA100P series
|
Current
|
85 A
|
0.9 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 42.5 mA
|
|
LT 100-S/SP37
LT100S&T series
|
Current
|
100 A
|
0.6 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
HAS 200-S/SP31
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-NPW-0A00
HOxx-NPW series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-PW
HOFxx-PW series
|
Current
|
300 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 205-S/SP15
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LT 300-T/SP41
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 150 mA
|
|
HAT 163-T/SP17
HAT series
|
Current
|
163 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP30-0100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOYS 300-S/SP606-1106
HOYS series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
LA 55-P/SP7
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 25 mA
|
|
LTC 350-SF/SP5
LTC350-500 series
|
Current
|
350 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
ATO-75-B1I-D10/SP1
ATO1B1I series
|
Current
|
75 A
|
1 %
|
Self Powered
|
Instantaneous
Current 75 mA
|
|
HLSR 50-P/SP8
HLSR series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HO 250-S-010D
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTB 75-P
HTB series
|
Current
|
75 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 310-S/SP11
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
DK 400 B420 B
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HO 100-S/SP30-0100
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HO 80-NPW-0A00
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTR 200-SB/SP1
HTR series
|
Current
|
200 A
|
2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LKSR 75-NP
LKSR series
|
Current
|
75 A
|
0.4 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.46875 V
|
|
HAS 200-S/SP1
HAS series
|
Current
|
200 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.5 V
|
|
HO 126-SW/SP4-0400
HOxx-SW- series
|
Current
|
126 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 250-PW
HOFxx-PW series
|
Current
|
250 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 200-P/SP3
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT 300-S/SP9
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 150 mA
|
|
ATO-75-B1I-D10/SP1
ATO1B1I series
|
Current
|
75 A
|
1 %
|
Self Powered
|
Instantaneous
Current 75 mA
|
|
HLSR 50-P/SP8
HLSR series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HO 250-S-010D
HOxx-S- series
|
Current
|
250 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTB 75-P
HTB series
|
Current
|
75 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LF 310-S/SP11
LF310 series
|
Current
|
250 A
|
0.2 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
DK 400 B420 B
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
22 to 38 V
|
Instantaneous
Current 4-20mA
|
|
HO 100-S/SP30-0100
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HO 80-NPW-0A00
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTR 200-SB/SP1
HTR series
|
Current
|
200 A
|
2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LKSR 75-NP
LKSR series
|
Current
|
75 A
|
0.4 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.46875 V
|
|
HAS 300-S/SP54
HAS series
|
Current
|
300 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 150-SW-0400
HOxx-SW- series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 300-P/SP1
HOF-P series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.5 V
|
|
LA 55-P/SP11
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 50 mA
|
|
LT 300-T/SP44
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 150 mA
|
|
HAT 320-T/SP17
HAT series
|
Current
|
320 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 205-SW/SP4-0400
HOxx-SW- series
|
Current
|
205 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HTB 100-TP/SP3
HTB series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 15 to 15 V
|
Instantaneous
Voltage Vc/2 +/- 1.66 V
|
|
LF 205-P/SP3
LF205 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 100 mA
|
|
LZSR 250-P/SP1
LZSR-P series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.675 V
|
|
DK 400 B420 U
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous unidirectional
Current 4-20mA
|
|
HO 100-S/SP32-0107
HOxx-S- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HOB 100-P/SP4
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LA 100-P/SP4
LA100P series
|
Current
|
100 A
|
0.9 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LPSR 50-NP/SP2
LPSR series
|
Current
|
50 A
|
0.45 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HAS 200-S/SP1
HAS series
|
Current
|
200 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.5 V
|
|
HO 126-SW/SP4-0400
HOxx-SW- series
|
Current
|
126 A
|
1.7 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HOF 250-PW
HOFxx-PW series
|
Current
|
250 A
|
1.6 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
LA 200-P/SP3
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 133 mA
|
|
LT 300-S/SP9
LT300 series
|
Current
|
300 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 150 mA
|
|
HAT 200-S/SP1
HAT series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HO 200-S/SP31-1100
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 1.65 +/- 0.8 V
|
|
HSNBV-D15
HSNBV series
|
Current
|
200 A, 600 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
LAC 300-S/SP8
LAC series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 50 mA
|
|
LTC 350-S/SP5
LTC350-500 series
|
Current
|
350 A
|
0.5 %
|
External DC Bipolar 15 to 24 V
|
Instantaneous
Current 175 mA
|
|
LTS 350-PB
LTS HC series
|
Current
|
350 A
|
0.8 %
|
External DC Unipolar 12 to 12 V
|
Instantaneous Unipolar
Voltage 6 +/- 1.4 V
|
|
HLSR 120-P/SP59
HLSR series
|
Current
|
120 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HLSR 50-P/SP39
HLSR series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LWSR 250-P
LWSR series
|
Current
|
250 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.781 V
|
|
AI-P1A
AI-P1A series
|
Current
|
100 A, 200 A, 300 A, 400 A, 500 A, 600 A, 800 A, 1000 A, 1500 A, 2000 A, 4000 A, 5000 A
|
0.5 %
|
External DC Unipolar 16.8 to 31.2 V
|
Instantaneous
Current 1000 mA
|
|
HOB 100-P
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HABT 100-V/SP20
HABT series
|
Current
|
100 A
|
3.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HAH1DRW 100-S/SP5
HAH1DRW series
|
Current
|
100 A
|
3.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HAH1DRW 200-S/SP5
HAH1DRW series
|
Current
|
200 A
|
3.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HAH1DRW 300-S/SP5
HAH1DRW series
|
Current
|
300 A
|
3.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
DHAB S/155
DHAB V2 series
|
Current
|
50 A, 800 A
|
3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HTRS 50 -SBI
HTRS series
|
Current
|
50 A
|
2 %
|
External DC Unipolar 12 to 24 V
|
Instantaneous
Current 4-20mA
|
|
HOB 100-P/SP1
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.6 V
|
|
HOB 50-P/SP1
HOB series
|
Current
|
50 A
|
1.45 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.6 V
|
|
HOB 100-P/SP33
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOB 50-P/SP33
HOB series
|
Current
|
50 A
|
1.45 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOB 100-P/SP34
HOB series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.92 V
|
|
HOB 75-P
HOB series
|
Current
|
75 A
|
1.35 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HOB 130-P
HOB series
|
Current
|
130 A
|
1.2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.04 V
|
|
HOB 75-P/SP1
HOB series
|
Current
|
75 A
|
1.35 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 1.6 V
|
|
HOB 130-P/SP1
HOB series
|
Current
|
130 A
|
1.2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2.08 V
|
|
HOB 75-P/SP33
HOB series
|
Current
|
75 A
|
1.35 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HOB 130-P/SP33
HOB series
|
Current
|
130 A
|
1.2 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.598 V
|
|
HOB 75-P/SP34
HOB series
|
Current
|
75 A
|
1.35 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.92 V
|
|
HOB 130-P/SP34
HOB series
|
Current
|
130 A
|
1.2 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 1.196 V
|
|
HOB 50-P
HOB series
|
Current
|
50 A
|
1.45 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
IN 100-S
IN100/200/400-S series
|
Current
|
100 A
|
0.0018 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 200 mA
|
|
IN 200-S
IN100/200/400-S series
|
Current
|
200 A
|
0.0012 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 200 mA
|
|
CAB-SF 500-C
CAB500S series
|
Current
|
-500 A, 500 A
|
0.8 %
|
External DC Unipolar 8 to 16 V
|
Instantaneous
Other CAN.c
|
|
HO 128-NP-0100
HOxx-NP- series
|
Current
|
128 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HLSR 100-P/SP10
HLSR-FeSi series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HLSR 120-P/SP10
HLSR-FeSi series
|
Current
|
120 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HLSR 80-P/SP10
HLSR-FeSi series
|
Current
|
80 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 0.8 V
|
|
HAS 200-S/SP58
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LZSR 150-TP
LZSR-TP series
|
Current
|
150 A
|
0.68 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 150-TP
LZSR-TP series
|
Current
|
150 A
|
0.68 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 100-P
LZSR-P series
|
Current
|
100 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 100-TP
LZSR-TP series
|
Current
|
100 A
|
0.68 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 80-P
LZSR-P series
|
Current
|
80 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 200-P/SP1
LZSR-P series
|
Current
|
200 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 200-TP/SP1
LZSR-TP series
|
Current
|
200 A
|
0.68 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LZSR 150-P/SP1
LZSR-P series
|
Current
|
150 A
|
0.83 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LF 310-S/SPA5
LF310 series
|
Current
|
300 A
|
0.2 %
|
External DC Bipolar 12 to 20 V
|
Instantaneous
Current 150 mA
|
|
AI-PMUL
AI-PMUL series
|
Current
|
100 A, 200 A, 300 A, 400 A, 500 A, 600 A, 800 A, 1000 A, 1500 A, 2000 A, 4000 A, 5000 A
|
0.5 %
|
External DC Unipolar 10 to 32 V
|
DC TRMS & Instantaneous
Other Multiple Current & Voltage
|
|
LAC 300-S/SP10
LAC series
|
Current
|
300 A
|
1.4 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 60 mA
|
|
HAH1BVW S/D08
HAH1BVW series
|
Current
|
350 A, 1200 A
|
2.2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 2.5 V
|
|
HO 150-PW-0A00
HOxx-PW- series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HO 200-PW-0A00
HOxx-PW- series
|
Current
|
200 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HO 250-PW-0A00
HOxx-PW- series
|
Current
|
250 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HX 50-P
HX series
|
Current
|
50 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HLSR 50-PW-010
HLSR-PW series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HLSR 50-PW-080
HLSR-PW series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HXN 50-P
HXN series
|
Current
|
50 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HSNDR-D01
HSNDR series
|
Current
|
100 A, 500 A
|
3 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
HSW S01
HSW Sxx series
|
Current
|
200 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage +/- 2.5 V
|
|
DHAB S/157
DHAB V2 series
|
Current
|
100 A, 350 A
|
3.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
DHAB S/161
DHAB V2 series
|
Current
|
100 A, 800 A
|
3.75 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HAM 250-S04
HAM series
|
Current
|
-250 A, 250 A
|
3.2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 2.5 V
|
|
DHAB S/160
DHAB V2 series
|
Current
|
30 A, 350 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HSNBV-D05
HSNBV series
|
Current
|
50 A, 400 A
|
3 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
HSNBV-D06
HSNBV series
|
Current
|
50 A, 300 A
|
3 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
HSNBV-D09
HSNBV series
|
Current
|
50 A, 500 A
|
3 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 0-5V
|
|
DHAB S/113
DHAB V2 series
|
Current
|
40 A, 400 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HAH1DRW 100-S
HAH1DRW series
|
Current
|
100 A
|
2.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
DHAB S/138
DHAB V2 series
|
Current
|
50 A, 450 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
DHAB S/159
DHAB V2 series
|
Current
|
100 A, 600 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HO 150-NPW-0000
HOxx-NPW series
|
Current
|
150 A
|
1.5 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HAH1BVW S/01
HAH1BVW series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HO 80-NPW-0000
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
HAH1BVW S/02
HAH1BVW series
|
Current
|
200 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
LESR 50-NP/SP1
LESR series
|
Current
|
50 A
|
0.7 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
CKSR 75-NP
CKSR-NP series
|
Current
|
75 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.46875 V
|
|
HAH1BVW S/03
HAH1BVW series
|
Current
|
300 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
DHAB S/113
DHAB V2 series
|
Current
|
40 A, 400 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HAH1DRW 100-S
HAH1DRW series
|
Current
|
100 A
|
2.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HO 80-NPW-0000
HOxx-NPW series
|
Current
|
80 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Other Pulse Density Modulation (PDM)
|
|
CKSR 75-NP
CKSR-NP series
|
Current
|
75 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.46875 V
|
|
HAH1BVW S/03
HAH1BVW series
|
Current
|
300 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
LESR 50-NP/SP1
LESR series
|
Current
|
50 A
|
0.7 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HAS 200-S/SP105
HAS series
|
Current
|
200 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 4 V
|
|
HAH1BVW S/D02
HAH1BVW series
|
Current
|
60 A, 350 A
|
2.2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 2.5 V
|
|
HO 150-P-0100
HOxx-P- series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LES 50-NP
LES series
|
Current
|
50 A
|
0.5 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LKSR 50-NP
LKSR series
|
Current
|
50 A
|
0.5 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LPSR 50-NP
LPSR series
|
Current
|
50 A
|
0.5 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LESR 50-NP
LESR series
|
Current
|
50 A
|
0.5 %
|
External DC Unipolar 5 to 5 V
5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LA 150-TP/SP1
LA130/150 series
|
Current
|
150 A
|
0.5 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 75 mA
|
|
DK 200 B420 U
DK series
|
Current
|
100 A, 150 A, 200 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous unidirectional
Current 4-20mA
|
|
HASS 300-S
HASS series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HO 60-NP-0100
HOxx-NP- series
|
Current
|
60 A
|
1.4 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HY 50-P/SP1
HY series
|
Current
|
50 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2 +/- 0.5 V
|
|
LA 55-P
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LF 306-S/SP10
LF306 series
|
Current
|
300 A
|
0.4 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 150 mA
|
|
DHAB S/134
DHAB V2 series
|
Current
|
50 A, 200 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HAIS 100-P
HAIS series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HC5FW 200-S
HC5FW series
|
Current
|
200 A
|
2 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 2 V
|
|
HOYS 100-S-0100
HOYS series
|
Current
|
100 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
LA 100-TP
LA100P series
|
Current
|
100 A
|
0.45 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LA 55-TP/SP27
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 25 mA
|
|
LT 100-S/SP30
LT100S&T series
|
Current
|
100 A
|
0.5 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 100 mA
|
|
DHR 100 C5
DHR series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 20 to 50 V
|
DC TRMS
Voltage 0-5V
|
|
HAIS 50-P
HAIS series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HO 100-P-0100
HOxx-P- series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTB 100-P
HTB series
|
Current
|
100 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LA 150-P/SP1
LA130/150 series
|
Current
|
150 A
|
0.5 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 150 mA
|
|
LA 200-P/SP4
LA200P series
|
Current
|
200 A
|
0.4 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LF 205-P
LF205 series
|
Current
|
200 A
|
0.5 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
DK 100 B5
DK series
|
Current
|
50 A, 75 A, 100 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
HO 200-S/SP33-1106
HOxx-S- series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 3.3 to 3.3 V
|
Instantaneous
Voltage 1.65 +/- 0.46 V
|
|
HTFS 200-P/SP2
HTFS series
|
Current
|
200 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage Uc/2 +/- 1.25 V
|
|
LA 255-S
LA255 series
|
Current
|
250 A
|
0.8 %
|
External DC Bipolar 12 to 18 V
|
Instantaneous
Current 125 mA
|
|
LF 210-S/SP11
LF210 series
|
Current
|
200 A
|
0.2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
CKSR 50-NP
CKSR-NP series
|
Current
|
50 A
|
0.8 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
DK 400 B420
DK series
|
Current
|
200 A, 300 A, 400 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Current 4-20mA
|
|
HASS 50-S
HASS series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HTB 50-TP
HTB series
|
Current
|
50 A
|
1 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Voltage 4 V
|
|
LA 205-S/SP6
LA205 series
|
Current
|
200 A
|
0.8 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
LF 210-S
LF210 series
|
Current
|
200 A
|
0.2 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 100 mA
|
|
DK 200 B420
DK series
|
Current
|
100 A, 150 A, 200 A
|
2 %
|
External DC Unipolar 20 to 50 V
|
Instantaneous Unipolar
Current 4-20mA
|
|
HASS 100-S
HASS series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HO 50-S-0100
HOxx-S- series
|
Current
|
50 A
|
1.25 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HXS 50-NP
HXS series
|
Current
|
12.5 A, 25 A, 50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
LA 306-S
LA306 series
|
Current
|
300 A
|
0.7 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 150 mA
|
|
LF 305-S/SP7
LF305 series
|
Current
|
250 A
|
0.5 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Current 125 mA
|
|
DHAB S/125
DHAB V2 series
|
Current
|
25 A, 200 A
|
3.3 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous Unipolar
Voltage 0-5V
|
|
LA 55-TP
LA55 series
|
Current
|
50 A
|
0.65 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 50 mA
|
|
LF 310-S/SP16
LF310 series
|
Current
|
300 A
|
0.2 %
|
External DC Bipolar 24 to 24 V
|
Instantaneous
Current 150 mA
|
|
DHR 100 C10
DHR series
|
Current
|
100 A
|
1 %
|
External DC Unipolar 20 to 50 V
|
DC TRMS
Voltage 0-10V
|
|
HAIS 150-TP
HAIS series
|
Current
|
150 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.625 V
|
|
HLSR 50-SM
HLSR-SM series
|
Current
|
50 A
|
1 %
|
External DC Unipolar 5 to 5 V
|
Instantaneous
Voltage 2.5 +/- 0.8 V
|
|
HTA 250-S/SP3
HTA series
|
Current
|
250 A
|
1 %
|
External DC Bipolar 15 to 15 V
|
Instantaneous
Voltage 10 V
|
|
LA 130-P/SP1
LA130/150 series
|
Current
|
130 A
|
0.5 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 65 mA
|
|
LAH 125-P
LAH125 series
|
Current
|
125 A
|
0.41 %
|
External DC Bipolar 12 to 15 V
|
Instantaneous
Current 125 mA
|
|
TT 100-SD
TT-SD series
|
Current
|
100 A
|
1 %
|
Self Powered
|
Instantaneous
Current 33.33 mA
|
|
DHR 300 C5
DHR series
|
Current
|
300 A
|
1 %
|
External DC Unipolar 20 to 50 V
|
DC TRMS
Voltage 0-5V
|
您的当前位置：
