Cincon AC-DC fanless power solution consists of baseplate-cooling power supplies and AC-DC brick type power supplies. The power range of baseplate-cooling power supplies starts from 130W to 500W and for the AC-DC brick, it has 70W. In addition, Cincon offers technical articles elaborating the outstanding performance of fanless power supplies. The suitable applications are industrial/ITE use with IEC/UL/EN 62368-1 safety approvals and medical use with IEC/UL/EN 60601-1 safety approvals.
ITE/Industrial Baseplate-cooled Open Frame
|
|
Model
|
Power
|
Input Voltage
|
Output Voltage
|
Features
|
Dimensions (Inch)
|
|
NEW
|
CFM130S
|
130W
|
80-264
|
12V, 18V, 19V, 24V, 36V, 48V
|
Altitude 5000m
Meets EN60335-1
ClassⅠ& Class Ⅱ
|
3.000x2.000x1.20 (Open-frame)
3.598x2.000x1.299 (Baseplate)
3.598x2.520x1.358 (Cover)
|
|
NEW
|
CFM150S
|
150W
|
90-264
|
12V, 24V, 28V, 36V, 48V
|
Altitude 5000m
Meets EN60335-1
Class I & Class II
|
4.00x2.00x1.283
(Open-frame)
4.598x2.00x1.362
(Baseplate)
|
|
NEW
|
CFM260S
|
260W
|
85-264
|
12V, 24V, 36V, 48V
|
Altitude 5000m
Meets EN60335-1
Class I
|
4.000x2.000x1.441
(Open-frame)
4.598x2.000x1.520
(Baseplate)
4.598x2.520x1.594
(Cover)
|
|
|
CFM300S
|
300W
|
90-264
|
12V, 24V, 36V, 48V
|
Altitude 5000m
Meets EN60335-1
Class I
|
5.000x3.000x1.421
(Baseplate)
5.355x3.425x1.591
(Cover)
|
|
NEW
|
CFM500S
|
500W
|
80-264
|
12V, 18V, 24V, 36V, 48V
|
Altitude 5000m
Meets EN60335-1
|
5.000x3.000x1.540
(Baseplate)
5.354x3.425x1.673
(Cover)
|
ITE/Industrial Brick Power
|
|
Model
|
Power
|
Input Voltage
|
Output Voltage
|
Features
|
Dimensions (Inch)
|
|
NEW
|
CBM70S
|
70W
|
90-264
|
12V, 24V, 36V, 48V
|
Low Profile
Wide Operating Temp.
Built-in EMI Filter & Capacitor
Class I
|
2.28x2.40x0.67
|
|
NRND
|
CBM100S
|
100W
|
90-264
|
12V, 24V, 28V, 36V, 48V
|
Build In Class B Filter
|
4.60x2.40x0.67
|
|
NEW
|
PDF700S
|
700W
|
90-264
|
12V, 24V, 28V, 48V, 56V
|
Low Profile
Built-in PFC
Altitude 5000
Class I
|
4.60x2.40x0.50
|
|
NEW
|
PFC750
|
750W
|
90-264
|
390V
|
Low Profile
Built-in PFC
Altitude 5000
|
2.28x2.40x0.50
|
Medical Baseplate-cooled Open Frame
|
|
Model
|
Power
|
Input Voltage
|
Output Voltage
|
Features
|
Dimensions (Inch)
|
|
NEW
|
CFM130M
|
130W
|
80-264
|
12V, 18V, 19V, 24V, 36V, 48V
|
2MOPP
Altitude 5000m
Meets EN60335-1
Class I & Class II
|
3.000x2.000x1.20
(Open-frame)
3.598x2.000x1.299
(Baseplate)
3.598x2.520x1.358
(Cover)
|
|
|
CFM200M
|
200W
|
90-264
|
12V, 24V, 48V
|
2MOPP
Class I & Class II
|
4.000x2.000x1.480
(Baseplate)
4.606x2.441x1.594
(Cover)
|
|
|
CFM300M
|
300W
|
90-264
|
12V, 24V, 36V, 48V
|
2MOPP
Class I
|
5.000x3.000x1.421
(Baseplate)
5.355x3.425x1.591
(Cover)
|
|
NEW
|
CFM500M
|
500W
|
80-264
|
12V, 18V, 24V, 36V, 48V
|
2MOPP
Altitude 5000m
Meets EN60335-1
Class I
|
5.000x3.000x1.540
(Baseplate)
5.354x3.425x1.673
(Cover)
|
|
